.Material: Top cover AL6061-T6
.Spec: Integrated 1-1/8” Upper/1.5” Bottom
(UP) Ø28.6 x Ø41.8mm / (DOWN) Ø39.5 x Ø51.8mm
.Cone Spacer Height: 15mm
.Bearing: (UPPER) 41.8 x 45° x 8
(LOWER) 51.8 x 45° x 8
.Weight: 78g/set
.Color: S.B Anodized Black
-
HA-S008 Manual
-
Documents Available for HA-S008
Technical Service Instructions (0.19 MB, PDF)
